Stumpjumper 15 Comp

Rammesett

• Ramme: FACT 11m karbon chassis og baktriangel, Trail Geometry, SWAT™ Door, justerbar styrevinkel, gjenget krankhus, intern kabelføring for brems og dropper, 12×148 mm bak, forseglede lager i pivoter, SRAM UDH kompatibel, 145 mm vandring
• Oppbevaring: SWAT 4.0 intern downtube storage
• Seteklemme: Aluminium, 38.6 mm

Demper

• Gaffel: FOX FLOAT 36 Rhythm, GRIP-demper, to-posisjons Sweep-justering, 15×110 mm, 44 mm offset, S1: 140 mm vandring, S2–S6: 150 mm vandring
• Bakdemper: FOX FLOAT Performance med Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-posisjons justering med LSR, S1: 210×52.5 mm, S2–S6: 210×55 mm

Bremser

• Forbrems: SRAM Maven Bronze, 4-stempel, hydraulisk skivebrems, 200 mm
• Bakbrems: SRAM Maven Bronze, 4-stempel, hydraulisk skivebrems, S1–S2: 180 mm, S3–S6: 200 mm

Drivverk

• Girhendel: SRAM AXS POD Controller
• Bakgir: SRAM S1000 Eagle Transmission
• Kassett: SRAM XS-1270 Transmission, 12-delt, 10–52T
• Kjede: SRAM GX Eagle Transmission Flattop
• Krank: SRAM S1000, 32T, integrert bashguard, 55 mm chainline, S1–S3: 165 mm, S4–S6: 170 mm
• Kranklager: SRAM DUB, BSA 73 mm Wide, gjenget

Hjul og dekk

• Felger: Specialized hookless aluminium, 30 mm innvendig bredde, tubeless ready, foran 29”, bak S1–S2: 27.5”, S3–S6: 29”
• Nav foran: Specialized aluminium, forseglede lager, 6-bolt, 15×110 mm, 32h
• Nav bak: Aluminium, forseglede lager, 12×148 mm, 28h
• Eiker: DT Swiss Industry
• Fordekk: Butcher GRID TRAIL, GRIPTON® T9, 2Bliss Ready, 29×2.3”
• Bakdekk: Eliminator GRID TRAIL, GRIPTON® T7, 2Bliss Ready, S1–S2: 27.5×2.3”, S3–S6: 29×2.3”
• Slanger: Standard Presta

Cockpit

• Stem: Alloy Trail Stem, 35 mm klemme
• Styret: Specialized 6000-serie aluminium, 6° upsweep, 8° backsweep, S1–S2: 780 mm bredde, 20 mm rise, S3–S4: 800 mm bredde, 30 mm rise, S5–S6: 800 mm bredde, 40 mm rise
• Holker: Specialized Trail Grips
• Sete: Bridge Comp, hul Cr-Mo rails, S1–S2: 155 mm, S3–S6: 143 mm
• Setepinne: X-Fusion Manic, trinnløs justering, 34.9 mm, S1: 125 mm, S2: 150 mm, S3: 170 mm, S4–S6: 190 mm

Vekt

• Vekt: 14.87 kg
• Referansestørrelse: S4
